Gigabyte H610M H DDR5 12th Gen Micro ATX Motherboard

Basic Information

Supported CPU

• LGA1700 socket: Support for 12th Generation Intel Core, Pentium Gold and Celeron Processors
• L3 cache varies with CPU

Chipset : Intel H610 Express Chipset

BIOS :

• 1 x 256 Mbit flash
• Use of licensed AMI UEFI BIOS
• PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Form Factor : Micro ATX Form Factor; 23.0cm x 21.5cm

Audio :

• Realtek Audio CODEC
• High Definition Audio
• 2/4/5.1/7.1-channel

Expansion Slots

PCI :

• 1 x PCI Express x16 slot, running at x16
• * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
• (The PCI Express x16 slot conforms to PCI Express 4.0 standard.)
• 1 x PCI Express x1 slot
• (The PCI Express x1 slot conforms to PCI Express 3.0 standard.)

Memory

Type : DDR5

Slots : 2 x DDR DIMM sockets

Supported Memory

• 3200/ 3000/ 2933/ 2666/ 2400/ 2133 MHz memory modules
• Dual channel memory architecture
• Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
• Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
• Support for Extreme Memory Profile (XMP) memory modules

Maximum Memory : Up to 64 GB (32 GB single DIMM capacity) of system memory

Graphics

Graphics :

Integrated Graphics Processor-Intel HD Graphics support:

• 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
• 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

* Support for HDMI 2.1 version and HDCP 2.3.

** Support native HDMI 2.1 TMDS compatible ports

Connector & Ports

HDMI : 1 x HDMI 2.0 port

D-Sub (s) : 1 x D-Sub port

USB (s)

Chipset:

• 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
• 4 x USB 2.0/1.1 ports on the back panel

Chipset+USB 2.0 Hub: 4 x USB 2.0/1.1 ports available through the internal USB headers

LAN Port (s) :  Intel GbE LAN chip (1 Gbps/100 Mbps)

Supported Storage

Chipset:

• 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 3.0 x4/x2 SSD support)
• 4 x SATA 6Gb/s connectors

Audio : 3 x audio jacks

Internal I/O Ports :

• 1 x 24-pin ATX main power connector
• 1 x 8-pin ATX 12V power connector
• 1 x M.2 Socket 3 connector
• 4 x SATA 6Gb/s connectors
• 1 x CPU fan header
• 2 x system fan headers
• 1 x RGB LED strip header
• 1 x front panel header
• 1 x front panel audio header
• 1 x USB 3.2 Gen 1 header
• 2 x USB 2.0/1.1 headers
• 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
• 1 x serial port header
• 1 x Clear CMOS jumper

TPM (Trusted Platform Module ) : 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)

Warranty Information

Manufacturing Warranty : 3 years

Others

Special Features :

• Support for APP Center
• * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
• @BIOS
• Ambient LED
• EasyTune
• Fast Boot
• Game Boost
• ON/OFF Charge
• Smart Backup
• System Information Viewer
• Support for Q-Flash
• Support for Xpress Install

Bundled Software :

• Norton Internet Security (OEM version)
• LAN bandwidth management software
